CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Front Panel Operation 6–68 MN-CDM570A
For Image#1 or Image #2, each image is further broken down to display component-level
firmware information.
(UTIL: FW Info) Image #X
Where Image#X denotes Image#1 or Image#2:
Image#X: Bulk Main-FPGA
App Legacy-FPGA CnC-FPGA
Use the
◄ ► arrow keys to select a parameter, and then press ENTER to display that firmware
component’s information. For example, when you select Bulk, a screen similar to the following
displays:
Bulk#X: 10/17/14
FW-0020683C 1.2.1
6.3.7.7.2 (UTIL: FW Images) Select
Current Active Image: #1
Next Reboot Image: #1 #2
The top line displays the currently loaded (active) image.
On the bottom line, use the
◄ ► arrow keys to select the image that will be loaded and active
upon the next unit reboot.
6.3.7.8 UTIL: FAST (FAST Code Options)
Chapter 5. FAST ACTIVATION PROCEDURE
FAST:Cnfg View (HW0.XXX)
MainBoard S/N: 123456789
FAST (Fully Accessible System Topology) provides the means to enable new options in the
modem. Contact Comtech EF Data during normal business hours to obtain the FAST Access
Code for the desired option.
The FAST menu allows you to configure (enter) a new FAST Access Code into the modem, view
which options are currently installed, and enable Demo Mode. This screen also identifies the
Hardware Revision Number on the top line, and the Main Board Serial Number on the bottom
line.
The MainBoard Serial Number is a unique identifier for the FAST upgrade process
and is different from the Chassis Serial Number. This number is required in order
to obtain a new FAST Access Code from Comtech EF Data Product Support.
Use the
◄ ► arrow keys to select Cnfg or View. Press ENTER.
