Comtech EF Data CDM-570AL - Common Odu Select Submenu; ODU SELECT:) Config

CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
ODU (Transceiver, BUC, LNB) Operation 10–10 MN-CDM570A
10.2.1.2.1.1.1 COMMON ‘ODU SELECT’ SUBMENU
(ODU: Transceiver Control) Enable►Standalone►
(ODU: Transceiver Control) Enable►1:1 ► CSAT#1 ►
(ODU: Transceiver Control) Enable►1:1 ► CSAT#2 ►
ODU SELECT: Config Info
Monitor Alarms (◄ ►,ENT)
Use the ◄ ► arrow keys to select Config, Info, Monitor, or Alarms, and then press ENTER.
10.2.1.2.1.1.1.1 (ODU SELECT:) Config
ODU CONFIG: Transmitter
Receiver Misc (◄ ►,ENT)
Use the ◄ ► arrow keys to select Transmitter, Receiver, or Misc, and then press ENTER.
(ODU CONFIG:) Transmitter
ODU TX: Frequency Atten
Amplifier Mute Slope ◄ ►
Use the ◄ ► arrow keys to select Frequency, Atten, Amplifier, Mute, or Slope, and then
press ENTER.
(ODU CONFIG ► ODU TX:) Frequency
ODU Tx Frequency:
5912.5 MHz (◄ ►,▲ ▼,ENT)
To edit the transmit frequency: First, use the ◄ ► arrow keys to select a digit, and then
use the ▲▼arrow keys to change the value of that digit. Press ENTER when done.
(ODU CONFIG ► ODU TX:) Atten (Attenuation)
ODU Tx Attenuation:
15.00 dB (◄ ►,▲ ▼,ENT)
To edit the transmit attenuation: First, use the ◄ ► arrow keys to select a digit, and then
use the ▲▼arrow keys to change the value of that digit. Press ENTER when done.
(ODU CONFIG ► ODU TX:) Amplifier
ODU Tx Amp State:
On Off (◄ ►,ENT)
Use the ◄ ► arrow keys to select On or Off, and then press ENTER.
