CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Optional Packet Processor - Serial/Telnet CLI Operation 9–16 MN-CDM570A
Selection
Hot Key
Description
SNMP Read Community
R
Select to enter community string (20 characters max).
SNMP Write Community
W
Select to enter community string (20 characters max).
SNMP Trap Community
T
Select to enter community string (20 characters max).
SNMP Trap Destination #1
D
Select to enter a value for the SNMP Trap Destination #1. Enter the
IP address in aaa.bbb.ccc.ddd format.
SNMP Trap Destination # 2
2
Select to enter a value for the SNMP Trap Destination #2. Enter the
IP address in aaa.bbb.ccc.ddd format.
SNMP Trap Version
V
Select to toggle between [SNMPv1] and [SNMPv2].
SNMP Enable Authentication
Trap
A
Select to toggle [Enabled] or [Disabled]:
SNMP System Contact
C
Select to enter text.
SNMP System Name
N
Select to enter text.
SNMP System Location
O
Select to enter text.
9.3.2.6 Administration > Working Mode
See Appendix D.
1. When you select Hot Key ‘C’ you are first prompted with:
“Changing Modem working mode requires system Reboot.
Do you want to continue (Y/N)[Enter :No]”
Press Y to continue; otherwise press N, [Enter], or [Esc] to quit and return to
the Administration page.
2. Working Mode is disabled when Brouter Mode VLAN Filtering is enabled. If
you attempt to select this item while configured as such, the following error
message displays:
“Can’t change Modem Working Mode when Brouter VLAN Filter is Enabled”
Once you elect to continue with configuration, you are prompted to select the active Working
Mode:
Selection
Description
1 – Router – Small Network
Router uses 1 byte HDLC addresses
2 – Router – Large Network
Router mode using 2 byte HDLC addresses
3 – Router – Point to Point
Router mode uses 0 HDLC addresses to save satellite bandwidth
4 – Router – Vipersat
Router mode when running in a Vipersat Network
5 – Managed Switch
Default operating mode, and operates at 10/100BaseT. In this mode the Packet
Processor will forward both IP and non-IP datagrams over satellite without any
defined routes.
