CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
ODU (Transceiver, BUC, LNB) Operation 1017 MN-CDM570A
(ODU SELECT ALARMS:) Stored View
LOG 02:11/13/99 10:42:47
OK- REF LOCK (▲ ▼)
Per the example shown, use the ▲▼arrow keys to sequentially view the individual
entries in the Stored Events Log. Otherwise, press CLEAR to return to the previous
menu.
(ODU SELECT ► ALARMS:) Stored Clear All
PRESS ENT TO
CLEAR THE EVENTS LOG
Press ENTER to clear the Stored Events Log. Otherwise, press CLEAR to return to the
previous menu.
10.2.1.2.2 (SELECT:) ODU KST-2000A/B Transceiver Operation
Figure 10-4 identifies the CDM-570A front panel menu hierarchy as it pertains specifically to
operation of the KST-2000A (LNA) or KST-2000B (LNB) ODU.
Figure 10-4. ODU: KST-2000A/B Transceiver Menu Tree
