CDM-570A/570AL Satellite Modem with Optional Packet Processor

Revision 5

Optional Packet Processor - Serial/Telnet CLI Operation 9–70 MN-CDM570A

9.3.10.2.1.1 Operations and Maintenance > Statistics Menu> IP Statistics >

Filter/Drop Statistics

Open the nested Filter/Drop Statistics page from the Statistics for IP Routing/EasyConnect page.

This page displays counts of the number of packets filtered or dropped in the Packet Processor.

Figure 9-54. Filter/Drop Statistics

Selection

Hot Key

Description

Reset All Counters

Clears and resets the Filter/Drop statistics buffer.
