CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Ethernet-based Remote Product Management 7–26 MN-CDM570A
7.4.3.2.8 Admin | PaP Save
This page is available only when you install the optional Packet Processor.
Figure 7-13. Admin | PaP Save Page
You must click [Save PaP Parameters] on this page, in addition to changes made to the
following CDM-570A HTTP Interface pages:
CDM-570A HTTP Interface Page Section
Admin | Pap Features 7.4.3.2.4
Admin | Firmware | Packet Processor 7.4.3.2.5.2
Configuration | LAN (only when the optional Packet Processor is
INSTALLED)
7.4.3.3.2
Configuration | ARP 7.4.3.3.3
Any nested Configuration | Routing page 7.4.3.3.4
Configuration | Managed Switch 7.4.3.3.5
Any nested Configuration | WAN page 0
Redundancy (only when the optional Packet Processor is INSTALLED) 7.4.3.6
Note that the modem reboots automatically if any changes are submitted to the ‘Admin |
Working Mode’ page (see Sect. 7.4.3.2.3).
