CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Front Panel Operation 6–50 MN-CDM570A
6.3.3.4 MONITOR: Event (Stored Events)
Stored Events: View
Clear-All (◄ ►,ENTER)
Use the
◄ ► arrow keys to select View or Clear-All. Press ENTER.
6.3.3.4.1 (MONITOR: Stored Events) View
Log23: 30/11/02 10:37:32
Fault - Demod Lock (▲ ▼)
When a fault condition occurs, the modem date- and time-stamps the fault, and enters it into the
Stored Events Log. The modem also records when the fault condition clears, as this example
shows:
Log240:30/11/97 10:37:35
Clear – Demod Lock(▲ ▼)
The Stored Events Log stores up to 255 events. Use the ▲▼arrow keys to browse through the
available entries. Press ENTER or CLEAR to return to the previous menu.
6.3.3.4.2 (MONITOR: Stored Events) Clear-All
Clear all Stored Events?
No Yes (▲ ▼, ENTER)
Use the ▲▼arrow keys to select No or Yes. Press ENTER.
When you select Yes, the modem clears the event log and returns you to the previous menu.
However, if a fault persists, the modem re-stamps the fault and generates a new log entry.
In accordance with European convention, the date appears in DAY-MONTH-
YEAR format.
