CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Carrier ID (DVB-CID MetaCarrier) R–3 MN-CDM570A
R.4 Configuring the CDM-570A/570AL for Carrier ID Operation
Carrier ID operation requires that you first enable Carrier ID feature operation, and then create a
MetaCarrier Custom Message. All other parameters (center frequency, symbol rate, and the
CDM-570A/570AL’s MAC address) are set automatically. The CDM-570A/570AL provides several
means for configuring Carrier ID operation:
• Local Control via the CDM-570A/570AL Front Panel keypad and VFD.
• Remote Control with a user-supplied PC via the
o CDM-570A/570AL HTTP (Web Server) Interface using a compatible Web browser.
o Serial-based or Telnet-based Remote Control Interface using a terminal emulation
program or Windows Command-line.
o Ethernet-based Simple Network Management Protocol (SNMP) using a Network
Management System (NMS) and Management Information Base (MIB) File Browser.
USE OF THE SERIAL-BASED REMOTE CONTROL INTERFACE, THE TELNET-
BASED REMOTE CONTROL INTERFACE, AND THE ETHERNET-BASED SNMP
INTERFACE ARE RECOMMENDED ONLY FOR ADVANCED USERS. COMTECH
EF DATA STRONGLY ENCOURAGES USE OF THE CDM-570A/570AL FRONT
PANEL OR HTTP (WEB SERVER) INTERFACE FOR MONITOR AND CONTROL
(M&C) OF THE CDM-570A/570AL.
R.4.1 Enabling Carrier ID Operation
R.4.1.1 Enabling Operation via the CDM-570A/570AL Front Panel and VFD
Sect. 6.3.7.9 UTIL: CID (Carrier ID) (Chapter 6. FRONT PANEL
OPERATION)
From the front panel main (SELECT:) menu, use the ◄ ► arrow keys to select the Utility menu
branch, and then press ENTER. Then, from the Utilities: screen, use the ◄ ► arrow keys to
select the CID submenu. Press ENTER to continue (the flashing solid block indicates the cursor
position upon navigation to that display item):
SELECT: Config Monitor
Test Info Save/Load Util
UTIL: Buf Clock Ref CMO
ID 1:1 VFD FW FAST CID
CarrierID: Off
To Next Page
