CDM-570A/570AL Satellite Modem with Optional Packet Processor

Revision 5

Optional Packet Processor - Serial/Telnet CLI Operation 9–41 MN-CDM570A

9.3.8 Satellite Modem

Open the Satellite Modem page from the Main Menu.

Figure 9-28. Modem Parameters

Selection

Hot Key

Description

Modem Type

[RO]

Identifies the Modem Type – CDM-570A or CDM-570AL.

Configuration C

Displays the Modem Configuration page.

See Section 9.3.8.1.

Monitor M

Displays the Modem Monitor page.

See Section 9.3.8.2.

Information I

Displays the Modem Information page.

See Section 9.3.8.3.

Utilities U

Displays the Modem Utilities page.

See Section 9.3.8.4.

9.3.8.1 Satellite Modem > Configuration

Open the nested Configuration page from the Satellite Modem page.

Figure 9-29. Modem Configuration
