CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Front Panel Operation 6–53 MN-CDM570A
In VersaFEC-2 ACM (V2-ACM) Mode:
Sta198:02/11/13 10:37:32
22.0, 22.0, 36, 00 (▲ ▼)
The modem calculates and then displays, on the top line from left to right, statistics data as
follows:
• (22.0, 22.0) First, the SNR is calculated: The minimum SNR value observed in the
measurement interval is provided first, and then the average SNR observed value
follows. The screen dislays 16.0 only if the measured values are ≥16.0 dB.
• (37) Maximum Rx ModCod, in decimal format, during the measurement interval.
• (37) Minimum Rx ModCod, in decimal format, during the measurement interval.
6.3.3.5.2 (MONITOR: Stats (Link Statistics)) Clear-All
Clear all Stored Stats?
No Yes (▲ ▼, ENTER)
Use the ▲▼arrow keys to choose No or Yes. Press ENTER. When you select Yes, the modem
clears the Link Statistics Log and returns you to the previous menu.
6.3.3.5.3 (MONITOR: Stats (Link Statistics)) Config (Configure)
Stats Logging Interval:
Disabled (▲ ▼,ENTER)
Valid logging interval settings (i.e., the time span, in minutes, over which the link statistics are
measured) are Disabled, 10, 20, 30, 40, 50, 60, 70, 80, or 90.
To select a logging interval the ▲▼arrow keys to select your desired interval setting. Press
ENTER. Once set, the display reflects the selected interval:
Stats Logging Interval:
30 minutes (▲ ▼,ENTER)
