CDM-570L/570AL Satellite Modem with Optional Packet Processor
Revision 5
Optional High Performance Packet Processor D–19 MN-CDM570A
D.1.3 CDM-570A/570AL-IP – Operation and Control
Functionality and selection of the CDM-570A/570AL-IP features, modes of operation, and monitor
and control (M&C) is seamless via these operational interfaces.
D.1.3.1 Front Panel Operation
Chapter 6. FRONT PANEL OPERATION
Using the keypad on the front panel, you may access a variety of nested
menus to configure the options available whenever the CDM-570A/570AL is
equipped with the optional Packet Processor.
D.1.3.2 Ethernet-based Remote Product Management
Chapter 7. ETHERNET-BASED REMOTE PRODUCT MANAGEMENT
The CDM-570A/570AL 10/100 BaseT Ethernet Management Interface supports three
management protocols for remote monitor and control (M&C) of the modem:
• Simple Network Management Protocol (SNMP) – This requires a user-supplied
Network Management System (NMS) and a user-supplied Management Information Base
(MIB) File Browser.
• Telnet Interface – This requires use of a user-supplied terminal emulation program
installed on the user PC, such as HyperTerminal (for use with the remote control
protocol) or PuTTY (for use with the Telnet Command Line Interface).
• CDM-570A HTTP (Web Server) Interface – This requires a compatible user-supplied
web browser such as Internet Explorer.
D.1.3.3 SNMP Interface
Sect. 7.2 SNMP Interface (Chapter 7. ETHERNET-BASED REMOTE PRODUCT
MANAGEMENT)
The Simple Network Management Protocol (SNMP) is an Internet-standard protocol for managing
devices on IP networks. An SNMP-managed network consists of three key components:
• The managed device – This includes the CDM-570A/570AL-IP.
• The SNMP Agent – The software that runs on the CDM-570A/570AL. The CDM-
570A/570AL-IP SNMP Agent supports both SNMPv1 and SNMPv2c.
• The user-supplied Network Management System (NMS) – The software that runs on
the manager.
