CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
ODU (Transceiver, BUC, LNB) Operation 10–39 MN-CDM570A
10.3.1.1.1.3 (CONFIG: Alarm Mask) LNB
LNB Alarm:
Active Masked (◄ ►,ENT)
Use the ◄ ► arrow keys to select Active or Masked, and then press ENTER. By selecting
Masked, no alarm will be generated.
10.3.1.1.2 CONFIG: ODU (Outdoor Unit)
ODU (Outdoor Unit):
BUC LNB (◄ ►,ENTER)
Use the ◄ ► arrow keys to choose between controlling and monitoring a BUC or an LNB. Press
ENTER when done
10.3.1.1.2.1 (CONFIG: ODU) BUC
BUC: M&C-FSK DC-Power
10MHz Alarm LO Mix (◄ ►)
Use the ◄ ► arrow keys to select M&C-FSK, DC-Power, 10MHz, Alarm, LO, or Mix, and then
press ENTER.
10.3.1.1.2.1.1 (CONFIG: ODU) BUC: M&C-FSK
BUC M&C(FSK): FSK-Comms
Address Tx-On/Off (◄ ►)
When an FSK-capable BUC is employed, use this menu to define, control and monitor the FSK
setup. Use the ◄ ► arrow keys to select Comms, Address, or Tx-On/Off. Press ENTER when
done
(CONFIG: ODU) BUC: M&C-FSK ►FSK-Comms
BUC M&C FSK Comms:
On Off (◄ ►,ENTER)
Use the ◄ ► arrow keys to select FSK communications between the modem and BUC as On
or Off. Press ENTER when done.
(CONFIG: ODU) BUC: M&C-FSK ►Address
BUC FSK Address: 01
(▲ ▼,ENTER)
To enter the logical address of the BUC: Use the ▲▼arrow keys to edit the value of the
address – the valid range is from 01 to 15 – and then press ENTER.
