Front Panel Operation 6–48 MN-CDM570A
6.3.3.1.1 (MONITOR: Live Alarms) Unit
Unit Fault: -12 Volt PSU
is Under-Voltage (ENT)
This screen displays Unit Faults. If none are present, it displays ‘None’. Press ENTER to return to
the previous menu.
6.3.3.1.2 (MONITOR: Live Alarms) Receive (Receive Traffic Status)
Rx Traffic: AGC Alarm -
Reduce Input level (ENT)
This screen displays Receive Traffic Faults. If none are present, it displays ‘None’. Press ENTER
to return to the previous menu.
6.3.3.1.3 (MONITOR: Live Alarms) Transmit (Transmit Traffic Status)
Tx Traffic: No Tx Clock
from Terrestrial (ENT)
This screen displays Transmit Traffic Faults. If none are present, it displays ‘None’. Press ENTER
to return to the previous menu.
6.3.3.2 MONITOR: Rx
EbNo>16.0dB BER=0.0E-9
ΔF=0.0k Buf=50 RSL=-42
With VersaFEC ACM (IP-ACM) or VersaFEC-2 ACM (V2-ACM) mode active:
SNR=22.0dB BER=0.0E-9
ΔF=+0.0k Buf=50 RSL=-49
To Next Page
