Comtech EF Data CDM-570AL - Figure 2-2. Install the Modem into a Rack Enclosure

To Next Page

To Previous Page

CDM-570A/570AL Satellite Modem with Optional Packet Processor

Revision 5

Installation and Startup 2–3 MN-CDM570A

Feature

Description

Custom Rack Enclosure

CDM-570A/570AL Satellite Modem

Standard Rack Shelving

Rack Enclosure Threaded Front Rail (typical)

Modem Front Panel

User-supplied Screws

Figure 2-2. Install the Modem into a Rack Enclosure
