CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Advanced Quality of Service (QoS) Option L–11 MN-CDM570A
L.1.4 VLAN – Priority/Max (VLAN-based Layer 2) QoS Mode
When selecting VLAN-based Layer 2 QoS, the priority field is extracted from the 802.1q VLAN
tag as shown in Figure L-1. The VLAN tag priority field is 3 bits, so the 802.1q protocol supports
eight priorities, from 0 to 7. However, because Layer 2 QoS has only four priorities as mentioned
previously, as shown in Table L-1 these eight VLAN priorities are automatically mapped to four
internal priories.
Similar to the Port-based scheduler, VLAN-based QoS also observes strict priority-based
scheduling. Should overdriving of VLAN priority traffic occur, the packet will be dropped and drop
stats will be incremented against that port.
Dest MAC
6 bytes
SRC MAC
6 bytes
Data
FCS
4 bytes
Type(0x8100)
2 bytes
Priority
3bits
CFI
1 bit
VLANid
12 bits
VLAN Tag
Figure L-1. IEEE 802.1q VLAN Priority
Table L-1. 802.1q to Layer 2 QoS Priority Conversion
802.1q VLAN Priority Field
Layer 2 QoS Priority
7 (b111)
Priority 1
6 (b110)
Priority 2
5 (b101)
Priority 3
4 (b100)
Priority 4
3 (b011)
Priority 5
2 (b010)
Priority 6
1 (b001)
Priority 7
0 (b000)
Priority 8
Even though it is not necessary to configure multiple ports with VLANs, the VLAN QoS will not
look in the port information when classifying the packets into queue.
In case VLAN Q-in-Q (double VLAN tag), the L2 VLAN QoS considers first VLAN
tag priority field only for traffic prioritization.
