If the ODU Redundancy system is in AUTO mode, a ‘forced switch-over’
can only occurs if the currently Offline unit is fault-free.
(ODU: Transceiver Control) Enable ►1:1 ► Redundancy Box ►
Mode
Operating Mode:
Manual Auto (◄ ►,ENT)
This screen indicates the current operating mode of the 1:1 ODU system. The cursor
will be flashing under Manual or Auto. If the need arises to change the operating mode of
the 1:1 system, use the ◄ ► arrow keys to move the cursor position to the desired
operating mode, and then press ENTER.
(ODU: Transceiver Control) Enable ►1:1 ► Redundancy Box ►
Switches
Waveguide Switch Status:
Tx=OK Rx=OK (ENT or CLR)
This read-only screen shows status for both the Tx and Rx Waveguide Transfer
Switches. If either Switch reports an ambiguity from the commanded position, “OK” will
change to “FT” to indicate a switch fault.
(ODU: Transceiver Control) Enable ► 1:1 ► Redundancy Box ►
Voltages
Redundancy Box Voltages:
5V= 5.0 12V=12.0 (ENT)
This read-only screen allows you to troubleshooting system problems. It monitors and
displays the voltages inside the Redundancy Controller Box.
To Next Page
