CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
ODU (Transceiver, BUC, LNB) Operation 10–11 MN-CDM570A
(ODU CONFIG ► ODU TX:) Mute
ODU Tx Mute State:
Muted Unmuted (◄ ►,ENT)
Use the ◄ ► arrow keys to select Muted or Unmuted, and then press ENTER.
(ODU CONFIG ► ODU TX:) Slope
ODU Tx Slope Mode:
Manual Calibrated (◄ ►)
Use the ◄ ► the arrow keys to select Manual or Calibrated, and then press ENTER.
(ODU CONFIG ► ODU TX:) Slope ► Manual
ODU Tx Slope:
0.0 (▲ ▼,ENT)
Use the ▲▼arrow keys to edit the transmit slope setting, and then press ENTER.
(ODU CONFIG ► ODU TX:) Slope ► Calibrated
Calibrate TX Slope?
Cal Exit (◄ ►,ENT)
Use the ◄ ► arrow keys to select Cal or Exit, and then press ENTER.
(ODU CONFIG:) Receiver
ODU RX: Frequency Atten
Mute Slope (◄ ►,ENT)
Use the ◄ ► the arrow keys to select Frequency, Atten, Mute, or Slope, and then press
ENTER.
(ODU CONFIG ► ODU RX:) Frequency
ODU Rx Frequency:
5912.5 MHz (◄ ►,▲ ▼,ENT)
To edit the receiver frequency: First, use the ◄ ► arrow keys to select a digit, and then
use the ▲▼arrow keys to change the value of that digit. Press ENTER when done.
(ODU CONFIG ► ODU RX:) Atten (Attenuation)
ODU Rx Attenuation:
15.00 dB (◄ ►,▲ ▼,ENT)
To edit the receiver attenuation: First, use the ◄ ► arrow keys to select a digit, and then
use the ▲▼arrow keys to change the value of that digit. Press ENTER when done.
