CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Front Panel Operation 6–70 MN-CDM570A
The bottom line provides a self-explanatory description for that option, along with its current
operational status (“Y” (Installed) or “N” (Not Installed)). Options listed as “N” are available for
purchase from Comtech EF Data.
AVAILABLE FAST OPTIONS
Option Number
Display Message
Option Type
01
150W BUC Power Supply
HARDWARE
02
100W BUC Power Supply
HARDWARE
03
10.239 Mbps data rate
FAST
04
RS Codec
FAST
05
TPC Codec
FAST
06
TPC 0.95 Card Present
HARDWARE
07
RESERVED
–
08
Tx VFEC 10.239 Mbps
FAST
09
8PSK/8QAM
FAST
10
16-QAM
FAST
11
Tx ROF 10.239 Mbps
FAST
12
G.703 Clock Extension
FAST
13
Carrier ID
FAST
14
CnC Card Present
HARDWARE
15
Full CnC 10.239 Mbps
FAST
16
Frac CnC datarate
FAST
17
CnC APC
FAST
18
PaP Card Present
HARDWARE
19
IP 3xDES Encryption
FAST
20
IP Header Compression
FAST
21
IP Payload Compression
FAST
22
IP QoS
FAST
23
Vipersat
FAST
24
VFS (Vipersat File Streamer)
FAST
25
IP-ACM 3000 ksps
FAST
26
Expansion Card (VsaFEC2 is
displayed when VF2 card is installed)
HARDWARE
