CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Ethernet-based Remote Product Management 7–57 MN-CDM570A
Re-Center Buffer
Click [Re-Center Buffer] to force the re-centering of the Plesiochronous/Doppler buffer.
Unit
Use the drop-down lists provided in this section to configure Test Mode, Stats Sample Interval,
Front Panel Lockout, RTS/CTS Control, and HSSI Handshake Control.
Click [Submit Unit Utilities] to save.
Clocks
Use the drop-down lists provided in this section to configure Tx / Rx Clock Sources, Rx Buffer
Size, External Clock, External Frequency Reference, and G.703 Clock Extended Mode /
Interface.
If “Internal plus output” is your active External Frequency Reference setting,
and you then set the modem to CDM-570 Compatibility Mode, the modem will
reset this feature to “Internal”. Reconfigure your setting as needed.
Click [Submit Clocks] to save.
Circuit ID
It is IMPORTANT to understand that Circuit ID is a distinct feature of the
CDM-570A/570AL. Read your documentation carefully.
Enter a Circuit ID string of up to 24 characters. You may use the following characters to compose
either string:
[Space] ( ) * + - , . / 0-9 and A-Z.
Date & Time
• Enter a date using DD/MM/YY format
(where DD = day [01 to 31], MM = month [01 to 12], and YY = year [00 to 99]).
• Enter a time using HH:MM:SS format
(where HH = hour [00 to 23], MM = minutes [00 to 59], and SS = seconds [00 to 59]).
Click [Enter Date/Time] once you set the desired date and time.
