CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Optional Packet Processor - Serial/Telnet CLI Operation 9–47 MN-CDM570A
Selection
Hot Key
Description
RX Code Rate
(continued)
4 – 2/3
5 – 3/4
6 – 7/8
7 – 0.95
8 – 1/1
9 – VersaFEC CCM BPSK 0.488
10 – VersaFEC CCM QPSK 0.533
11 – VersaFEC CCM QPSK 0.631
12 – VersaFEC CCM QPSK 0.706
13 – VersaFEC CCM QPSK 0.803
14 – VersaFEC CCM 8-QAM 0.576
15 – VersaFEC CCM 8-QAM 0.642
16 – VersaFEC CCM 8-QAM 0.711
17 – VersaFEC CCM 8-QAM 0.780
18 – VersaFEC CCM 16-QAM 0.644
19 – VersaFEC CCM 16-QAM 0.731
20 – VersaFEC CCM 16-QAM 0.780
21 – VersaFEC CCM 16-QAM 0.829
22 – VersaFEC CCM 16-QAM 0.853
23 – VersaFEC ULL BPSK 0.493
24 – VersaFEC ULL QPSK 0.493
25 – VersaFEC ULL QPSK 0.654
26 – VersaFEC ULL QPSK 0.734
27 – VersaFEC-2 ModCod_0 – BPSK 0.489
28 – VersaFEC-2 ModCod_1 – QPSK 0.489
29 – VersaFEC-2 ModCod_2 – QPSK 0.537
30 – VersaFEC-2 ModCod_3 – QPSK 0.586
31 – VersaFEC-2 ModCod_4 – QPSK 0.611
32 – VersaFEC-2 ModCod_5 – QPSK 0.635
33 – VersaFEC-2 ModCod_6 – QPSK 0.660
34 – VersaFEC-2 ModCod_7 – QPSK 0.684
35 – VersaFEC-2 ModCod_8 – QPSK 0.733
36 – VersaFEC-2 ModCod_9 – 8_ARY 0.521
37 – VersaFEC-2 ModCod_10 – 8_ARY 0.537
38 – VersaFEC-2 ModCod_11 – 8_ARY 0.562
39 – VersaFEC-2 ModCod_12 – 8_ARY 0.586
40 – VersaFEC-2 ModCod_13 – 8_ARY 0.611
41 – VersaFEC-2 ModCod_14 – 8_ARY 0.635
42 – VersaFEC-2 ModCod_15 – 8_ARY 0.660
43 – VersaFEC-2 ModCod_16 – 8_ARY 0.684
44 – VersaFEC-2 ModCod_17 – 8_ARY 0.708
45 – VersaFEC-2 ModCod_18 – 8_ARY 0.733
46 – VersaFEC-2 ModCod_19 – 16_ARY 0.586
47 – VersaFEC-2 ModCod_20 – 16_ARY 0.611
48 – VersaFEC-2 ModCod_21 – 16_ARY 0.635
49 – VersaFEC-2 ModCod_22 – 16_ARY 0.660
50 – VersaFEC-2 ModCod_23 – 16_ARY 0.684
51 – VersaFEC-2 ModCod_24 – 16_ARY 0.708
