DoubleTalk Carrier-in-Carrier Option G–19 MN-CDM570A

Step Task

3 Calculate change in Eb/No and verify against specification.

Example Link:

• Recorded Eb/No = 2.5 dB

• Change in Eb/No = 0.2 dB

• Eb/No Degradation (Spec.) at 1.2 dB PSD = 0.3 dB

• Modem performance is within spec
