18. Jam Display Field Service Ver. 1.0 Aug. 2005
224
bizhub 200/250/350
Troubleshooting
18.3 Solution
18.3.1 Initial Check Items
• When a paper misfeed occurs, first make checks of the following initial check items.
Check Item Action
Does paper meet product specifications? Change paper.
Is paper curled, wavy, or damp.
Change paper.
Instruct user in correct paper storage.
Is a foreign object present along the paper path, or
is the paper path deformed or worn?
Clean or change the paper path.
Are the Paper Separator Fingers dirty, deformed, or
worn?
Clean or change the defective Paper Separator
Finger.
Are rolls/rollers dirty, deformed, or worn? Clean or change the defective roll/roller.
Are the Edge Guide and Trailing Edge Stop at cor-
rect position to accommodate paper?
Set as necessary.
Are actuators found operational as checked for cor-
rect operation?
Correct or change the defective actuator.
To Next Page
