Field Service Ver. 1.0 Aug. 2005 11. Soft Switch List
121
FK-503Adjustment / Setting
NOTE
• The features with (*) are settable by users. *: Screen setting <*>: Soft switch setting
MODE Factory setting bit
382
Bit: 7654 3210
0100 0000
HEX:40
Bit Feature
Logic
Description
01
7 IP Relay Process result
timeout <*>
Commu-
nication
error
Commu-
nication
com-
pleted
Specify the communication result when
a timeout occurs by IP Relay result wait-
ing (instruction machine).
6 IP Relay Set result time-
out <*>
Bit 6-3: 0000 0 min Specify the period of a
timeout of IP Relay
result waiting (instruction
machine).
5 0001 5 min
4 0010 10 min
3 0011 15 min
0100 20 min
0101 30 min
0110 40 min
0111 50 min
1000 1 hr
1001 2 hr
1010 3 hr
1011 4 hr
1100 5 hr
1101 6 hr
1110 7 hr
1111 8 hr
2 Set default relay station
for IP Relay *
Bit 2-0:
000 Relay
station 1
Set the default relay
instruction machine for
IP Relay (instruction
machine).
1 001 Relay
station 2
0 010 Relay
station 3
011 Relay
station 4
100 Relay
station 5
101 Relay
station 6
110 Relay
station 7
111 Relay
station 8
