Field Service Ver. 1.0 Aug. 2005 11. Soft Switch List
129
FK-503Adjustment / Setting
NOTE
• The features with (*) are settable by users. *: Screen setting
MODE Factory setting bit
413
Bit: 7654 3210
0000 0100
HEX:04
Bit Feature
Logic
Description
01
7 Select FAX (G3-1) output
bin. *
Bit 7-6:
00 First tray
output
• Specify a tray to
where FAX (G3-1)
document is delivered
to when the finisher
has been attached.
• “Additional bin output”
is valid only when the
additional bin is
attached.
6 01 Second tray
output
10 Additional bin
output
11 Not available
5 Select PC print output bin.
*
Bit 5-4:
00 First tray
output
• Specify a tray to
where PC print is
printed out when the
finisher is attached.
• “Additional bin output”
is valid only when the
additional bin is
attached.
4 01 Second tray
output
10 Additional bin
output
11 Not available
2 Select copy output bin. * Bin 1
Bin 2 Specify a bin to where copied document
is delivered to when the job separator
has been attached.
1 Select FAX (G3-1) output
bin. *
Bin 1 Bin 2 Specify a bin to where faxed (G3-1) doc-
ument is delivered when the job separa-
tor has been attached.
0 Select PC print output bin.
*
Bin 1 Bin 2 Specify a bin to where PC print is deliv-
ered to when the job separator has been
attached.
To Next Page
