Dräger Fabius User Manual

Operation
106
Instructions for Use Fabius MRI SW 3.n
The parameters that can be set for SIMV/PS mode
are shown the adjacent table, along with their
adjustment ranges and factory default values.
z To access the Trigger, Insp Flow,TINSP, and
TIP:TI parameters, press the »MORE« key on
the SIMV/PS screen.
z After the mode change is confirmed, the
»SIMV/PS« key LED switches from blinking to
constantly on, the ventilator switches to the
SIMV/PS mode, and the waveform is restored.
Ventilation Parameter
(SIMV/PS Mode)
Adjustment
Range
Factory
Default
Value
Pressure Limitation
P
MAX [cmH2O] ([hPa])
15 to 70
min. PEEP+10
and
>
ΔPPS+PEEP
40
Tidal Volume
VT [mL]
20 to 1100 600
Frequency
Freq [bpm] ([1/min])
4 to 60 12
Support pressure
ΔPPS [cmH2O] ([hPa])
3 to 20, OFF 10
PEEP [cmH
2O] ([hPa]) 0 to 20 0
Trigger Sensitivity
Trigger [L/min]
2 to 15 2
Inspiratory Flow
Insp Flow
[L/min]
10 to 85 30
SIMV insp. time
T
INSP [seconds]
0.3 to 4.0 1.7
Insp pause time:
Insp time
T
IP:TI [%]
0 to 50 10

Dräger Fabius Specifications

General

Type	Anesthesia Workstation
Display	Color TFT
Gas Supply	O2, N2O, Air
CO2 Absorber	Yes
Manufacturer	Dräger
Model	Fabius
Ventilation Modes	SIMV
Inspiratory Time	0.2-5 s
PEEP	0 to 20 cmH2O
Vaporizer Mounts	2
O2 Flow	0 to 15 L/min
Air Flow	0 to 15 L/min
