Instructions for Use Fabius MRI SW 3.n 33
System Overview
Symbol Definition
The following symbols appear on the labels on the
back of the Fabius MRI and are defined below:
The following symbols are used on other locations
of the Fabius MRI to provice quick and easy recog-
nition of product functions.
Caution:
Refer to accompanying documents
before operating equipment.
Caution:
Risk of electric shock, do not
remove.
Degree of protection agains elec-
tric shock: Type BF
Certification mark for Canada and
USA
Date of manufacture
Fuse
Catalogue number
Serial number
Oxygen Concentration Sensor
Port
Breathing Pressure Sensor Port
Breathing Volume Sensor Port
Ventilator Port
Pipeline Gauge, Pipeline inlet
Breathing Bag
CUS
REV
SN
Flowmeter Level Indicator
Indicates Direction
Total Power Applied
Partial Power Applied
Cylinder Gauge, Remote Cylinder
Inlet
Do Not Oil
ESD warning symbol:
Do not touch contacts of interface
if not electrostatically discharged.
No known hazards in a specified
MR environment with specified
conditions of use.
Distance to MRT magnetic
strength ≤40 mtesla (400 gauss)
Device central brake has to be
locked at the desired position
beside the MRI immediately!
Use only MR labeled cylinders
Do not use any type of Desflurane
vaporizer in MR environment
Consult Instructions for Use
Use–by date
CAUTION:
After positioning
in the MRI room
always lock the
casters by
pressing the Central
Brake Lever !
YYYY-MM
