34 Instructions for Use Fabius MRI SW 3.n
System Overview
The following symbols are used on the Fabius MRI
monitoring user interface.
Observe leakage current
Rx only CAUTION: USA Federal law
restricts this device to sale by or on
the order of a physician.
Transportation label,see page 114
CO2 absorbent bypass
Vaporizer plug-in system
O
2-Flush
Upper and Lower Alarm Limits
Return to Home Screen
Suppress Alarm Tone for Two Min-
utes
Suppress Alarm Tone for Two Min-
utes*
Standby Mode
Available Operating Capacity of
UPS
Close Menu, Back to Previous
Menu
Upper Alarm Limit
Lower Alarm Limit
Mains Applied/Mains Power
+
+
_
XX %
Alarm Off
Alarm Off*
Setup Screen
connection for equipotential bond-
ing
* as of SW 3.20

Dräger Fabius Specifications

General

Type	Anesthesia Workstation
Display	Color TFT
Gas Supply	O2, N2O, Air
CO2 Absorber	Yes
Manufacturer	Dräger
Model	Fabius
Ventilation Modes	SIMV
Inspiratory Time	0.2-5 s
PEEP	0 to 20 cmH2O
Vaporizer Mounts	2
O2 Flow	0 to 15 L/min
Air Flow	0 to 15 L/min
