20 Instructions for Use Fabius MRI SW 3.n
System Overview
Rear View (Pin-Index Connector)
1 Connector for medical gas pipeline supply (cen-
tral supply)
2 Sealed connector
3 Type plate
4 Ventilator hose connection
5 Interface panel
6 ON/OFF switch
7 Fuse
8 Compact Breathing System (COSY)
9 Power cable connection
10 Pin-Index system
11 Potential equalization pin
12 Auxiliary power outlets
100
12
5
4
6
8
10
7
3
12
9
11
