Dräger Fabius User Manual

Technical Data
208
Instructions for Use Fabius MRI SW 3.n
Anesthetic Agent Vaporizer Interface
Dräger Halothane Vapor 2000
Dräger Enflurane Vapor 2000
Dräger Isoflurane Vapor 2000
Dräger Sevoflurane Vapor 2000
Dräger Vapor quick-change plug-in system for up to two anesthetic agent vaporizers.
The connections are automatically closed and sealed when the vaporizer is removed.
Vapor 2000 system only
See specific Instructions for Use manuals for technical data of anesthetic agent vaporizers.
Monitoring and Measurement Display Range Resolution Accuracy Condition
P
AW Airway pressure (numeric) –20 to 99 cmH2O
(hPa)
1 cmH2O
(hPa)
±4 %
1)
1) Max. ±4 % of the measured value or ±2 cmH2O (±2 hPa), whichever is greater.
Airway pressure (wave) 0 to 99 cmH2O
(hPa)
Pressure gauge (mechanical) –20 to 80 cmH
2O
(hPa)
5 cmH2O
(hPa)
1.6 cmH2O
(hPa)
V
E Expiratory minute volume 0 to 99.9 L/ min 0.1 L/ min ±15 %
2)
2) At standard test conditions per IEC 60601-2-13.
with reference
to 68 °F (20 ° C),
ambient pres-
sure and satu-
rated gas
Expiratory tidal volume 0 to 1500 mL 1 mL ±15 %
2)
or
±20 mL,
whichever is
greater
f Breathing frequency 2 to 99 bpm
(1/min)
±1 bpm
(1/min)
±1 bpm
(1/min)
FiO
2 O2 measurement in the
main gas flow
10 to 100 vol.% 1 vol.% ±(2.5 vol.%
+ 2.5% of the
measured
value) as per
ISO 21647
with reference
to ambient pres-
sure during cali-
bration

Dräger Fabius Specifications

General

Type	Anesthesia Workstation
Display	Color TFT
Gas Supply	O2, N2O, Air
CO2 Absorber	Yes
Manufacturer	Dräger
Model	Fabius
Ventilation Modes	SIMV
Inspiratory Time	0.2-5 s
PEEP	0 to 20 cmH2O
Vaporizer Mounts	2
O2 Flow	0 to 15 L/min
Air Flow	0 to 15 L/min
