Technical Data
198
Instructions for Use Fabius MRI SW 3.n
Dimensions and Weight (Approximate)
Weight:
Base unit with COSY and without supplementary 365.5 lb (165.8 kg)
Base unit with COSY and two vaporizers;
without additional supplementary
403 ib (182.8 kg)
Dimensions W x H x D
Base unit (caster) with central brake unlocked
Base unit (caster) with central brake locked
approx. 30.7 x 55 x 35.5 in (78 x 140 x 90 cm)
approx. 30.7 x 55 x 36.3 in (78 x 140 x 92 cm)
Dimensions W x H x D
(with COSY, left or right side mounted)
1)
approx. 39 x 55 x 35.5/36.3 in (99 x 140 x 90/92 cm)
Height writing tray 38.5 in (86 cm)
Height Teslameter sensoric 37.8 in (96 cm)
1) Width may vary with COSY arm position
Fuses
Mains fuses For 100 to 240 V supply voltage:
2x T2.5 AL 250 V IEC 60127-2/V
Fuses located on circuit board 1x T1.6AL 250 V IEC 60127-2/III
1x T4AL 250 V IEC 60127-2/III
1x T2.5AL 250 V IEC 60127-2/III
Battery fuse 1x T3.15AH 250 V IEC 60127-2/V
Tesla Sensor
Range of the Tesla sensor 35 to 45 mtesla

Dräger Fabius Specifications

General

Type	Anesthesia Workstation
Display	Color TFT
Gas Supply	O2, N2O, Air
CO2 Absorber	Yes
Manufacturer	Dräger
Model	Fabius
Ventilation Modes	SIMV
Inspiratory Time	0.2-5 s
PEEP	0 to 20 cmH2O
Vaporizer Mounts	2
O2 Flow	0 to 15 L/min
Air Flow	0 to 15 L/min
