Dräger Fabius User Manual

222 Instructions for Use Fabius MRI SW 3.n
Anesthetic Gas Scavenging System
P
 Check the hose connections.
P
 Adjust the flow regulator to place the float
between the "Minimum" and "Maximum"
marks.
P
 Change to Man/Spont mode.
Press and hold the O
2 flush button and ver-
ify that airway pressure is <10 cmH
2O
(hPa) with Y-piece occluded.
Wait until flow curve is refreshed.
P
 Close all flow control valves on the
machine, with Y-piece occluded, and verify
that airway pressure is ≥0.5 cmH
2O (hPa)
Manual Ventilation Bag for Emergency Ventila-
tion
 Check that the bag is functioning correctly
by pumping manually.
 When the bag is squeezed, air must audi-
bly and tangibly flow out of the mask cone;
when the bag is released, it must rapidly
recover its original shape.
 Block off the mask connector (cone) with
the ball of your thumb: you should only be
able to squeeze the bag a little.
P  Before Connecting to Patient
Verify that
– all vaporizers are off (the handwheels
are set to zero),
– the APL Valve is set as desired,
– all flowmeters indicate 0,
– the patient suction is level adequate,
and
– the breathing system is ready to use
(the bag is in place and all hoses are
connected properly
If any check can not be carried out satisfacto-
rily, the machine must not be used.
Daily Checkout Signature
Name
Date
Pre-use Checkout Signature
Name
Date
Pre-use Checkout Signature
Name
Date
Pre-use Checkout Signature
Name
Date
Pre-use Checkout Signature
Name
Date

Dräger Fabius Specifications

General

Type	Anesthesia Workstation
Display	Color TFT
Gas Supply	O2, N2O, Air
CO2 Absorber	Yes
Manufacturer	Dräger
Model	Fabius
Ventilation Modes	SIMV
Inspiratory Time	0.2-5 s
PEEP	0 to 20 cmH2O
Vaporizer Mounts	2
O2 Flow	0 to 15 L/min
Air Flow	0 to 15 L/min
