Programming
154 Service Instructions M-TYPE DELTA - 00.0 - 12/2019
• Program selection Bit B7
• Program selection Bit B8
• Program selection Bit B9
• Short stitch
•2
nd
edge guide position (height)
•2
nd
edge guide position (gap and height)
• DB3000
• DB2000
• Function module 1
• Function module 2
• Function module 3
• Function module 4
• Function module 5
• Function module 6
• Function module 7
• Function module 8
• Sewing light
• Machine head lighting
• Sewing foot lift
•2
nd
position sewing foot lift
Each input can be switched to Latching or Hold to run.
Output Configuration
Configure and allocate the outputs here. The table shows the outputs and
their allocation. The pins on the PCB are labeled and must be allocated
according to the table, depending on what was connected to the pin.
Each output can be assigned one of the following modes.
• Sewing foot lift
• Needle thread tension
• Thread trimmer
• Needle cooling
• NSB knife
• NSB block
• Pos. 1
• Pos. 2
