Programming
Service Instructions M-TYPE DELTA - 00.0 - 12/2019 181
Test Material Thickness Sensor sub-item
Use this sub-item to test the functionality of the material thickness sensor.
Fig. 127: Test Material Thickness Sensor sub-item
To test the material thickness detection:
1. Open the menu Service > Multi test > Test Material
Thickness Sensor.
2. Lift the sewing feet.
3. Place the sewing material under the sewing feet.
4. Lift the sewing feet.
 The signal quality (1) must display the value 1.
(1) - Signal quality
Parameter Description
Signal quality
Signal quality of the sensor
Height of the sewing foot lift
indicates the height of the sewing foot lift for
the current sewing material
Sewing foot stroke
indicates the sewing foot stroke for the current
sewing material
Sewing foot pressure
indicates the sewing foot pressure for the
current sewing material
Speed
indicates the set speed
Needle thread tension
indicates the needle thread tension for the
current sewing material
①
