Sewing feet
70 Service Instructions M-TYPE DELTA - 00.0 - 12/2019
Sewing foot pressure
Proper setting
The sewing material does not slip and is correctly transported. The correct
sewing foot pressure depends on the sewing material:
• Lower pressure for soft materials, e.g. fabric
• Higher pressure for durable materials, e.g. leather or laminate
The sewing foot pressure is set via the program parameters ( p. 156).
Height of the sewing foot lift
Proper setting
The distance between the raised sewing feet and the throat plate is preset
on delivery.
This distance is preset to 18 mm on machines with a short thread cutter.
The height of the sewing foot lift is set via the program
parameters ( p. 156).
When the pedal is pressed back halfway, the sewing feet can be raised
during sewing, e. g. to move the sewing material.
When the pedal is pressed completely back, the sewing feet will be raised
after the thread is cut so that the sewing material can be removed.
