2.4.1 Emergency stop button
Fig. 1: Emergency stop button
When the emergency stop button is actuated, the system is immediately transferred into
safe operating mode.
For safety reasons, in cases where the controller (e.g. "MyControl") cannot be installed
in the immediate vicinity of the ELADOS Compact, an emergency stop button can be
installed on the metering unit or on the machine side.
WARNING!
The master switch may only be actuated/unlocked when the cause of the
EMERGENCY shutdown has been clarified and rectified.
The system must then be started up again.
Safety
20MAN046590 Rev. 6-03.2022
