Ecolab ULTRAX Compact - 13.4 Oval gear meter OGMPLUS; 13.4.1 Technical data; 13.4.1.1 Materials

13.4
Oval gear meter OGM
PLUS
13.4.1 T
echnical data
Oval gear meter type: 00112 00540 01200 02100 04500
Article no.
280141 280043 10240555
280
044
280045
28004
6
(EBS no.)
10200631
100929
43
On request
100
133
57
10106904
10100
572
Article no.
280151 280073 10240556
280
074
280077
28007
8
(EBS no.)
10200632
102006
27
On request
102
006
28
10200629
10200
630
Recommended for metering pump EMP
II/KKS
(0.9...1
1.2
l/h)
EMP III
(16...54l
/h)
EMP III
(80...120l/h)
EMP IV
(140...210l
/h)
EMP
IV
(450l/h
)
Flow rate when using an EMP
metering pump [l/h]
Min.
0,5* 4,8 18 40 60
Max. 13,5 65 144 250 540
Flow rate with continual
throughput [l/h]
Min. 1,25 12 45 100 150
Max. 34 160 360 625 1200
Number of pulses with
connection to primary control
unit (e.g. PLC)**
ml/
pulse 1 5 5 10 20 50
Number of pulses if connected to
E60 electronics (high-definition)
ml/
pulse
0,01 0,029 0,055 0,133 0,222
permissible system pressure
[bar]
Max.
10
Ambient temperature/
temperature of medium [°C]
Max.
40
Viscosity [mPas] Max. 1000
Accuracy
Not calibrated (delivery state)
Calibrated under operating conditions
± 5 %
± 1%
Connection thread
G1/8" G1/4"
G3/
4" *
G1 1/4"
* For E60+ electronics control, a minimum throughput of 1 l/h is required.
** The device can be programmed for other pulse sequences within the processing limits.
13.4.1.1 Materials
Housing PVC, gray or PP (280048)
Housing cover PVC (transparent) or PP (280048)
O-ring seals FPM (Viton B) optional EPDM
Oval gear wheels PVDF (for type 00112), PVC (for type 00112)
PEEK (for typs 00540, 01200, 02100, 04500)
Oval gear spindles Ceramic
Technical data
107 MAN046590 Rev. 6-03.2022
