Ecolab ULTRAX Compact - A Installation checklist

A Installation checklist
General data
Customer name:
TCD ULTRAX
Compact:
Device number:
Date of installation:
Address:
Tel: Fax: Email:
Ecolab field rep:
ECOLAB technician:
Contact partner:
Water supply
Checklist Yes No Comment
Backflow preventer required and installed?
o o
Shut-off device available between the water supply and the
water valve?
o o
Dynamic water pressure of at least 2 bar available?
o o
Maximum water temperature of 30° C?
o o
Compressed air supply
Checklist Yes No Comment
Compressed air line Ø 10 / 16 used?
o o
Sufficient pressure present; valves working?
o o
Maintenance unit in working order?
o o
Mechanical Installation
Checklist Yes No Comment
PLC control unit with integrated emergency off switch mounted
immediately next to the rack?
o o
If not, separate emergency off switch installed on rack?
o o
Emergency off switch freely accessible?
o o
Wall mount stable/cap nut seating checked?
o o
Suction pipes marked with product labels?
o o
Splash curtain mounted properly?
o o
All hoses/pipes installed free of kinks?
o o
Leakage switch checked for freedom of movement and
function?
o o
Electrical installation
Checklist Yes No Comment
Bridges in the controller set independent of the signal strength
o o
Shielded cable for signal voltages from 12 to 90 volts
o o
Voltage supply, signal cable and empty messages free of
tension
o o
Electrical socket safeguard installed and inspected
o o
Mains cable routing / strain relief / cable glands tightened
o o
Installation checklist
115 MAN046590 Rev. 6-03.2022
