Controller Setup "MyControl"
Checklist Yes No Comment
Calibration values stored for pumps?
o o
Rinsing or flushing activated?
o o
Wireless channel set for multiple controller installation?
o o
Selection of action after program end selected?
o o
Mechanical function test
Checklist Yes No Comment
Possible to manually activate pumps?
o o
Intake process of product okay?
o o
Tightness of lines and components checked (pumps, valve
blocks, rinse valves, oval wheel meters, screw connections,
line parts etc.) ?
o o
Acoustics check for unusual noises?
o o
Electrical Function Test
Checklist Yes No Comment
Main switch function given?
o o
Assignment and control of servo valves, valve blocks and rinse
valves?
o o
Input of the signals at the controller (controller possible via test
screen at the controller)?
o o
Double handle on the program selection box resets controller
(Applies only to installations with program selection box)?
o o
Function of the connected empty signal given?
o o
Function of the connected flow monitor given?
o o
Function oval wheel meter?
o o
Reset of the controller and program selection box given?
o o
Send data to controller or receive data from controller?
o o
Customer Instructions – Products / Safety
Check list - Instructions Installed Products Yes No Comment
Safety data sheet
o o
Safety data sheet
o o
Safety data sheet
o o
Safety data sheet
o o
Safety data sheet
o o
Safety data sheet
o o
Checklist – Safety Instructions Yes No Comment
Collecting tray(s)
o o
Storage for chemicals
o o
Drip pan(s)
o o
Checklist – Recurring Tests Yes No Comment
Regular inspection of the backflow preventer
o o
Regular check on threaded joints
o o
Regular check on metering lines
o o
Additional remarks
Date:
Installation checklist
116MAN046590 Rev. 6-03.2022
