6.2 Machine assignment Diaphragm valve manifold block – machine side
Use PE-X hoses, type A, Raupex, D12/16 on the "diaphragm valve manifold
block - machine side"
1. The hoses for connecting the washer extractors must be connected to the screw
connections of the valve block as shown in
Ä Chapter 6.1 ‘Product assignment, diaphragm valve manifold block – product side’ on page 46
.
The following machine assignments apply:
Configuration
