7.4 Upgrading the pilot valve
Installation step:
1. Remove the reserve plug (No.1) from the island
2. Place the solenoid valve (no. 2) at the place that has become free and fix in position
3. Electrical terminal plate (no. 3)
4. Connect on both sides.
Installation
56MAN046590 Rev. 6-03.2022
