13 Technical data
13.1 General
Data Value Unit
Supply voltage (1/N/PE AC):
230 V 50 Hz / 24 V DC
Back-up fuse:
Max. 10 A
Power consumption:
Max. 200 FA
Device type of protection:
33 IP
Protection class
1
Ambient temperature:
10 - 40 °C
Water temperature (cold water):
Max. 30 °C
Water flow pressure, dynamic:
min 0.2 (2.0) MPa (bar)
Water flow pressure, static:
max 0.6 (6.0) MPa (bar)
Compressed air supply:
min 0.6 (6.0) MPa (bar)
Emissions noise pressure level:
> 70 dB(A)
Metering back pressure pumps (standard equipment):
max 1.0 (10) MPa (bar)
Metering output per pump (standard equipment):
54 Litres/h
Pump type of protection:
55 IP
Dimensions incl. wall spacer grommets (W x H x D):
1150 x 1580 x 470 mm
Weight:
ca. 70 Kg
Working temperature range, lower temperature limit:
+5 °C
Working temperature range, upper temperature limit:
+40 °C
Working temperature range
control cabinets / control devices:
≤40 °C
Working temperature range
Relative humidity (non-condensing):
max. 65 %
Storage conditions, lower temperature limit:
-10 °C
Storage conditions, upper temperature limit:
+50 °C
Storage conditions
Relative humidity (non-condensing):
max. 65 %
Workplace lighting to be provided by owner/operator,
in acc. with ASR 7/3, recommended
Ex = 300 Lux
The scope of delivery does NOT include any system separation
for safeguarding in accordance with the drinking water requirement
DIN EN 1717!
See
Ä Chapter 11.2 ‘Optional equipment ULTRAX Compact’ on page 77
It is essential that you observe the standards and regulations that apply
to you!
If required, please contact us (
Ä Chapter 1.10 ‘Contact’ on page 13 ).
