13.2.1.3 General data
Description
Type
00160
Type
00250
Type
00540
Type
00800
Type
01200
Pump output [l/h]*/** 16 25 54 80 120
Max. metering back-pressure [MPa (bar)]** 1 (10) 0,4 (4) 0,3 (3)
Stroke quantity [1/min] at 50 Hz 122
Dosage rate/stroke [cm³] 50 Hz/60 Hz 2,1 3,4 7,3 10,8 16,1
Reproduction accuracy [
Ä Chapter
13.2.1.9 ‘Metering rates depending on back-
pressure and stroke setting’ on page 101 ]
< ± 3%
Max. conveyable viscosity [mPas] 200
Permissible ambient temperature 5–40°C
Suction height [mWS] at 100% stroke setting*** 2
Max. suction side pre-pressure [MPa (bar)] 0,05 (0,5)
Noise level (DBA) at 1 m distance
(according to DIN EN 12639/ EN ISO 9614-2)
48,0
Recommended minimum diameter of suction/
pressure connection [ID mm]
6 mm PVC hose
6/12, 10/16
12 mm PVC hose
12/21
Weight [kg] 7,4 8,6
* Values determined with water as the metering medium at a temperature of 20 °C.
** At a line frequency of 60 Hz, the delivery capacity increases by 20% and the metering back-pressure drops by 20%.
*** Suction heights determined with clean, moistened valves at 100% stroke and max. stroke frequency.
DANGER!
With reference to DIN EN 809 5.2.3, please be advised that the surface
temperature of the motor may exceed 80°C under certain circumstances.
Therefore, ensure that this area cannot be touched during operation!
Tightening torques
NOTICE!
It is essential that the tightening torques given below are observed, firstly to
ensure the leak-tightness of the system and secondly to ensure the integrity of
the thread. The tightening torques are also given on an adhesive label that is
affixed to the pump head.
Pump head size 5 l/h and 11 l/h 30 l/h and 50 l/h 120 l/h
Tightening torque of the suction/pressure valves: 2 ± 0.2 Nm 2,8 ± 0.2 Nm 4 ± 0.2 Nm
Tightening torque of the metering head screws: 3,75 ± 0.25 Nm 6 ± 0.25 Nm 6 ± 0.25 Nm
13.2.1.3.1 Differing general data – “Higher Pressure (HP)” pump versions
Description Type 00160 Type 00250
Pump output [l/h]* 14,7 23,5
Max. metering back-pressure [MPa (bar)] 1,6 (16) 1,2 (12)
Dosage rate/stroke [cm³] 1,98 3,15
* Values determined with water as the metering medium at a temperature of 20 °C.
