Illustration Description
Filter pressure regulator
Keeping the set compressed air pressure constant for the servo valves.
Ä
Chapter 4 ‘Layout’ on page 39 , Fig. 4 , No. 3
and
Ä
Appendix B.3 ‘Filter pressure regulator’ on page 134 .
Terminal boxes including pilot valves
Includes serial terminal boards and servo valves for controlling the diaphragm valve
manifold blocks.
Ä
Chapter 4 ‘Layout’ on page 39 , Fig. 4 , No. 2 & 20
and
Ä
Appendix C ‘Terminal Connections Plan’ on page 141 .
Function description
45 MAN046590 Rev. 6-03.2022
