6227 - 3
english
Mounting plate 1/2" or 3/4"
internal thread
Mounting
module, left
Terminating
module
DN 10 base module dual,
triple or quad
Valve set type 6227
DN 10
DN 10 insert
(fitted with manifold or distributor
function depending on the installation
position)
Sensor holder
Lower connections:
3/8" internal thread
Hose connection
3/4" outer thread
3/4" outer thread with
check valve
Valve set type 6227
DN 13
DN 13 insert
(fitted with manifold or distributor
function depending on the installation
position)
DN 13 base module dual
or triple
Terminating module
Mounting
module, right
Mounting plate 1/2" or 3/4"
internal thread
2.2 Diagram of the modular combinable water valve
