User Manual Section 4
GFK-2958L May 2021
Detailed Descriptions of the Fieldbus Network Adapters 102
Register address
(in hex)
Process image length in bits for the
output modules
Process image length in bits for the input
modules
Register mapping revision
Collective diagnostics message for I/O
modules
(1 bit per I/O module)
Collective process alarm message for I/O
modules
(1 bit per I/O module)
Module status (2 bits per I/O module) 00
= module OK, 01 = module error 10 =
incorrect module 11 = module not
plugged in
Structure as in
PROFIBUS module
status
MODBUS DATA EXCHANGE watchdog,
current time (x*10ms) 0 = watchdog has
expired 0xFFFF = watchdog deactivated
Time still remaining
for monitoring the
exchange of process
data
MODBUS DATA EXCHANGE watchdog,
predefined time (x*10ms), default = 0ms
(no watchdog active)
Time for monitoring
the exchange of
process data
MODBUS DATA EXCHANGE watchdog
reset register
Bit0 = 1: watchdog reset at predefined
time
Bit8 = 1: restart after expired watchdog
Bit 0: reset watchdog
while it is running
(retrigger)
Bit 8: restart of
expired watchdog
Lock of the “Force Mode” via Webserver
LOCK to lock,
FREE to unlock
Changing IP Address 1 via Fieldbus
Changing Subnet Mask 1 via Fieldbus
Changing Gateway 1 via Fieldbus
MODBUS CONNECTION mode register
MODBUS CONNECTION timeout in sec.
Default = 1 (0 not allowed)
Check the reference list before data
exchange
0x0000 = disable, 0x0001 = enable
Process alarm 0x0000 = disable, 0x0001
= enable
Diagnostics alarm 0x0000 = disable,
0x0001 = enable
Behavior in case of field bus error and
reference list error
0x0000 = all outputs to 0, 0x0001 = set
error values
0x0002 = retain process data
