Detailed Descriptions of the Fieldbus Network Adapters 103
Register address
(in hex)
Access
Data width
Description
Remarks
0x1136
rw
Word
Behavior when module removed
0x0000 = process data continues to run
0x0001 = behavior as with field bus error
0x1137
rw
Word
Data format 0x0000 = Motorola, 0x0001
= Intel
0x113C – 0x113D
wo
Long
Restore module parameters
Motorola =“LOAD”, Intel =“DAOL”
Corresponds to the
“DEFAULT” in the
web server
0x113E – 0x113F
wo
Long
Save module parameters
Motorola =“SAVE”, Intel =“EVAS”
Corresponds to
“SAVE” in the web
server
0x1140 – 0x1141
rw
Long
Changing IP Address 2 via Fieldbus
These registers only
available with
EPXMBE101
0x1142 – 0x1143
rw
Long
Changing Subnet Mask 2 via Fieldbus
0x1144 – 0x1145
rw
Long
Changing Gateway 2 via Fieldbus
0x27FE
ro
Word
Number of entries in the current module
list
0x27FF
ro
Word
Number of entries in the reference
module list
0x2800 – 0x287F
rw
Long
Reference module list
(max. 64 modules per station * 2
registers per module)
There must always
be 2, 4, 6 etc.
registers transferred
0x2A00 – 0x2A7F
ro
Long
Current module list
(max. 64 modules per station * 2
registers per module)
There must always
be 2, 4, 6 etc.
registers transferred
0x8000 – 0x87FF
ro
Module
Process data inputs
(max. 64 modules per station * 32
registers per module)
0x9000 – 0x97FF
rw
Module
Process data outputs
(max. 64 modules per station * 32
registers per module)
0xA000 – 0xA7FF
ro
Byte
Diagnostics
(max. 64 modules per station * 32
registers per module)
Confirmation by
readout
0xB000 – 0xB7FF
ro
Byte
Process alarms
(max. 64 modules per station * 32
registers per module)
Confirmation by
readout
0xC000 - 0xC7FF
(Firmware 01.xx.xx)
0xC000 - 0xFFFF
(Firmware 02.00.00
or higher
rw
Byte
Module parameters
(Firmware 01.xx.xx:
max. 64 modules per station * 32
registers per module;
Firmware 02.00.00 or higher:
max. 64 modules per station * 256
registers per module)
Note: If the user wants to access the DWORD for EP-5111, EP-5112, EP-5212, EP-5442 and EP-5422 modules use
SWAP_DWORD function block.
