Emerson PACSystems RSTi-EP - Page 52

User Manual Section 3
GFK-2958L May 2021
Configuration 38
Product
Part No.
Parameter
Optional values
Default value
Module behavior on hot
swap
Continue data exchange /
Behavior like fieldbus error
Continue data
exchange,
see register
0x1136
Data format
Motorola / Intel
Motorola,
see fieldbus
register 0x1137
EtherNet/IP
Network
Adapter, 2 Cu
RJ45 Ports
EPXEIP001
IP-Address
4 numbers between 0-255
0.0.0.0
Subnet mask
4 numbers between 0-255
255.255.255.0
Gateway
4 numbers between 0-255
0.0.0.0
IP Configuration
Static, DHCP, BootP
DHCP
IP-Address USB Port
192.168.1.202;
192.168.2.202,
192.168.3.202,
192.168.4.202, 192.168.5.202
192.168.5.202
Webserver via Ethernet
disabled / enabled
enabled
Save module parameters
no / yes / Standard
no
Output Behavior on idle
state
All outputs off (0) / Enable
substitute values (1) / Hold last
value (2)
All outputs off
Process alarm
disabled (0) / enabled (1)
disabled
Diagnostic alarm
Disabled (0) / enabled (1)
disabled
Behavior of outputs on
fieldbus error
All outputs off (0) / Enable
substitute values (1) / Hold last
value (2)
All outputs off
Module behavior on hot
swap
Continue data exchange (0) /
Behavior like fieldbus error (1)
Continue data
exchange
Data format
Motorola (0) / Intel (1)
Intel
Lock force mode
Force mode unlocked / Force
mode locked
Force mode
unlocked
HTTPS setting
HTTP & HTTPS concurrent
operation/ Only HTTPS; no
HTTP
Only HTTPS; no
HTTP
Digital Input,
4 Points, Positive
Logic 24Vdc,
2-, 3-, or 4-Wire
EP-1214
Ch 0 … Ch 3:
Input delay
no (0)/
0.3ms (1) (not at PROFIBUS-
DP)/
3ms (2)/
10ms (3)/
20ms (4)/
40ms (5) (not at PROFIBUS-DP)
3ms
Digital Input,
8 Points, Positive
Logic, 24Vdc
2-Wire
EP-1218
Ch 0 … Ch 7:
Input delay
no (0) /
0.3ms (1) (not at PROFIBUS-
DP) /
3ms (2) /
10ms (3) /
20ms (4) /
40ms (5) (not at PROFIBUS-DP)
3ms
Digital Input,
8 Points, Positive
Logic, 24Vdc
3-Wire
EP-1318
