Emerson PACSystems RSTi-EP - Page 53

User Manual Section 3
GFK-2958L May 2021
Configuration 39
Product
Part No.
Parameter
Optional values
Default value
Digital Input,
4 Points, Positive
Logic 24Vdc,
2-, 3-, or 4-Wire,
Time stamp
EP-12F4
Ch 0 … Ch 3:
Input delay
no (0) /
0.3ms (1) (not at PROFIBUS-DP) /
3ms (2) /
10ms (3) /
20ms (4) /
40ms (5) (not at PROFIBUS-DP)
3ms
Ch 0 … Ch 3:
Timestamp at edge 0-1
disabled (0) /
enabled (1)
disabled
Ch 0 … Ch 3:
Timestamp at edge 1-0
disabled (0) /
enabled (1)
disabled
Digital Output,
4 Points, Positive
Logic 24Vdc,
0.5A,
2-, 3-, or 4-Wire
EP-2214
Ch 0 … Ch 3:
Substitute value
Off (0) / On (1)
Off
Digital Output,
4 Points, Positive
Logic 24Vdc,
2.0A,
2-, 3-, or 4-Wire
EP-2614
Digital Output,
4 Points,
Positive/
Negative Logic
24Vdc, 2.0A,
2-, 3-, or 4-Wire
EP-2634
Ch 0 … Ch 3: Substitute
value OP-Mode
Sinking (0) /
Sourcing (1)
Sourcing
Ch 0 … Ch 3:
Substitute value
Off (0) / On (1)
Off
Digital Output,
8 Points, Positive
Logic, 24Vdc,
0.5A,
2-Wire
EP-2218
Ch 0 … Ch 7:
Substitute value
Off (0) / On (1)
Off
Digital Output,
4 Points, Positive
Logic, 230Vac,
1A
EP-2814
Ch 0 … Ch 3:
Substitute value
Off (0) / On (1)
Off
Digital Relay
Output,
4 Points,
Positive Logic,
24 – 220
Vdc/Vac, 6A,
2-Wire
EP-2714
