Emerson PACSystems RSTi-EP - Page 62

User Manual Section 3
GFK-2958L May 2021
Configuration 48
Product
Part No.
Parameter
Optional values
Default value
Current alarm upper limit
enable
disabled (0) / enabled (1)
disabled
Current alarm upper limit
0 ... 5 A (0 ... 27648)
100% = 0x6C00
Current imbalance alarm
enable
disabled (0) / enabled (1)
disabled
Current imbalance alarm
limit
0 ... 100% (0 ... 16383)
100%
Frequency alarm lower limit
enable
disabled (0) / enabled (1)
disabled
Frequency alarm lower limit
45 ... 65 Hz (5760 ... 8320)
45 Hz
Frequency alarm upper
limit enable
disabled (0) / enabled (1)
disabled
Frequency alarm upper
limit
45 ... 65 Hz (5760 ... 8320)
65 Hz
Power factor alarm enable
disabled (0) / enabled (1)
disabled
Power factor alarm lower
limit
0 ... 1 (0 ... 16383)
0
Diagnostic alarm
disabled (0) / enabled (1)
disabled
Channel 0 ... 7: Measuring
value
RMS voltage L1 (0) / L2 (1) / L3
(2)
RMS voltage average (3)
RMS current L1 (4) / L2 (5) / L3
(6)
RMS current average (7)
Peak current L1 (8) / L2 (9) / L3
(10)
Line frequency (11)
Harmonic power L1 (12) / L2
(13) / L3 (14)
Harmonic reactive power L1
(15) / L2 (16) / L3 (17)
Harmonic apparent power L1
(18) / L2 (19) / L3 (20)
Power factor L1 (21) / L2 (22) /
L3 (23)
Total power factor (24)
Harmonic voltage L1 (25) / L2
(26) / L3 (27)
Harmonic current L1 (28) / L2
(29) / L3 (30)
Active power L1 (31) / L2 (32) /
L3 (33)
Active power total (34)
Reactive power L1 (35) / L2
(36) / L3 (37)
Reactive power total (38)
Apparent power L1 (39) / L2
(40) / L3 (41)
Apparent power total (42)
