Emerson PACSystems RSTi-EP - Page 61

User Manual Section 3
GFK-2958L May 2021
Configuration 47
Product
Part No.
Parameter
Optional values
Default value
Analog Input, 4
Channels TC 16
Bits with
Diagnostics 2-,
3-, or 4-Wire
EP-3804
Temperature unit
Degree Celsius (0) /
Degree Fahrenheit (1) /
Degree Kelvin (2)
Degree Celsius
Ch 0 … Ch 3 Measurement
range
TC Type J (0) /
TC Type K (1) /
TC Type N (2) /
TC Type R (3) /
TC Type S (4) /
TC Type T (5) /
TC Type B (6) /
TC Type C (7) /
TC Type E (8) /
TC Type L (9) /
TC Type U (10) /
± 15.625 mV (11) /
± 31.25 mV (12) /
± 62.5 mV (13) /
± 125 mV (14) /
± 250 mV (15) /
± 500 mV (16) /
± 1,000 mV (17) /
± 2,000 mV (18) /
disabled (19)
disabled
Ch 0 … Ch 3
Cold junction
compensation
internal (0) /
external Channel 0 (1)/
external Channel 1 (2) /
external Channel 2 (3) /
external Channel 3 (4)
internal
Ch 0 … Ch 3 Conversion
time
240ms (0) /
130ms (1) /
80ms (2) /
55ms (3) /
43ms (4) /
36ms (5)
80ms
Ch 0 … Ch 3 Channel
diagnostics
disabled (0) /
enabled (1)
disabled
Ch 0 … Ch 3 Limit value
monitoring
disabled (0) /
enabled (1)
disabled
Ch 0 … Ch 3
High limit value
-32,768 ... 32,767
0
Ch 0 … Ch 3
Low limit value
-32,768 ... 32,767
0
Power
Measurement
Module, 8
Channels
EP-1813
Current range
1 A (0) / 5 A (1)
1 A
Harmonic select
1 ... 31 (1 ... 31)
1 = fundamental
Voltage alarm lower limit
enable
disabled (0) / enabled (1)
disabled
Voltage alarm lower limit
0 ... 300 V (0 ... 27648)
0 = 0x0
Voltage alarm upper limit
enable
disabled (0) / enabled (1)
disabled
Voltage alarm upper limit
0 ... 300 V (0 ... 27648)
300 V = 0x6C00
Current alarm lower limit
enable
disabled (0) / enabled (1)
disabled
Current alarm lower limit
0 ... 5 A (0 ... 27648)
0 = 0x0
